01 Aug 2012
Blogger Label Widget Style #3 and #4

Tag Cloud design
Tag Clouds are used to display all the categories or labels present in a blog. The inherent design of this widget in Blogger is very minimal and has a lot of space for creativity. In this post we will be showcasing two Label Widget designs which you can easily integrate within your blog. Both these use :after and :before selectors to manipulate the tag's design at the edges. Also CSS3 Gradients and Box-Shadow properties are also used to give it more sophisticated and peppy look . Lets get started then



Just a Second
Before you get started make sure that your Blog has the Label Widget present already and set the Display option to Cloud . After you have done this then only proceed to the next

Also Don't forget to checkout the Design #1 and Design #2 of the Label Styles.

Design #3
Label tag cloud design blogger

Demo

To add using One Click Installer Method



Or just add the following CSS in your Blog(preferably before the ]]></b:skin> tag in the Edit HTML of the Template)
.label-size{
 margin:0;
 padding:0;
 position:relative;
 }
 .label-size a{
 float:left;
 height:24px;
 line-height:24px;
 position:relative;
 font-size:12px;
 margin-bottom: 9px;
 margin-left:20px;
 padding:0 10px 0 12px;
 background:#0089e0;
 color:#fff;
 text-decoration:none;
 -moz-border-radius-bottomright:4px;
 -webkit-border-bottom-right-radius:4px;
 border-bottom-right-radius:4px;
 -moz-border-radius-topright:4px;
 -webkit-border-top-right-radius:4px;
 border-top-right-radius:4px;
 }
.label-size a:before{
 content:"";
 float:left;
 position:absolute;
 top:0;
 left:-12px;
 width:0;
 height:0;
 border-color:transparent #0089e0 transparent transparent;
 border-style:solid;
 border-width:12px 12px 12px 0;
 }
.label-size a:after{
 content:"";
 position:absolute;
 top:10px;
 left:0;
 float:left;
 width:4px;
 height:4px;
 -moz-border-radius:2px;
 -webkit-border-radius:2px;
 border-radius:2px;
 background:#fff;
 -moz-box-shadow:-1px -1px 2px #004977;
 -webkit-box-shadow:-1px -1px 2px #004977;
 box-shadow:-1px -1px 2px #004977;
 }

.label-size a:hover{background:#555;}
.label-size a:hover:before{border-color:transparent #555 transparent transparent;}



Want to get these updates straight to your Inbox , Then Subscribe !

Design #4
Label tag design for blog

Demo
To add using One Click Installer Method



Or just add the following CSS in your Blog(preferably before the ]]></b:skin> tag in the Edit HTML of the Template)

.label-size a {
    display: inline-block;
    text-decoration: none;
    text-shadow: 0 1px 0 rgba(255, 255, 255, 0.4);
    padding: 4px 7px;
    font-family: 'Helvetica Neue', helvetica, sans-serif;
    font-size: 12px;
    line-height: 14px;
    height: 14px;
    vertical-align: middle;
    margin-bottom: 6px;
    -webkit-border-radius: 4px;
    -moz-border-radius: 4px;
    border-radius: 4px;

    -webkit-box-shadow: 0 1px 1px 0 rgba(0, 0, 0, 0.2), inset 0 1px 0 0 rgba(255, 255, 255, 0.4);
    -moz-box-shadow: 0 1px 1px 0 rgba(0, 0, 0, 0.2), inset 0 1px 0 0 rgba(255, 255, 255, 0.4);
    box-shadow: 0 1px 1px 0 rgba(0, 0, 0, 0.2), inset 0 1px 0 0 rgba(255, 255, 255, 0.4);
}


.label-size a {
    color: #996633;
    border: 1px solid #DDA13C;

    background: rgb(238,177,75);
    background: -moz-linear-gradient(top,  rgba(238,177,75,1) 0%, rgba(204,145,45,1) 100%);
    background: -webkit-gradient(linear, left top, left bottom, color-stop(0%,rgba(238,177,75,1)), color-stop(100%,rgba(204,145,45,1)));
    background: -webkit-linear-gradient(top,  rgba(238,177,75,1) 0%,rgba(204,145,45,1) 100%);
    background: -o-linear-gradient(top,  rgba(238,177,75,1) 0%,rgba(204,145,45,1) 100%);
    background: -ms-linear-gradient(top,  rgba(238,177,75,1) 0%,rgba(204,145,45,1) 100%);
    background: linear-gradient(top,  rgba(238,177,75,1) 0%,rgba(204,145,45,1) 100%);
    filter: progid:DXImageTransform.Microsoft.gradient( startColorstr='#eeb14b', endColorstr='#cc912d',GradientType=0 );
}

.label-size a:before  {
    content: '\2022';
    color: #FFFFFF;
    margin-right: 4px;
    font-size: 15px;
    line-height: 13px;
    height: 13px;
    vertical-align: text-top;

    text-shadow: 0 -1px -1px rgba(0, 0, 0, 0.2);
}

.label-size a:hover {
    text-decoration: none;

    background: rgb(240,183,86);
    background: -moz-linear-gradient(top,  rgba(240,183,86,1) 0%, rgba(214,160,68,1) 100%);
    background: -webkit-gradient(linear, left top, left bottom, color-stop(0%,rgba(240,183,86,1)), color-stop(100%,rgba(214,160,68,1)));
    background: -webkit-linear-gradient(top,  rgba(240,183,86,1) 0%,rgba(214,160,68,1) 100%);
    background: -o-linear-gradient(top,  rgba(240,183,86,1) 0%,rgba(214,160,68,1) 100%);
    background: -ms-linear-gradient(top,  rgba(240,183,86,1) 0%,rgba(214,160,68,1) 100%);
    background: linear-gradient(top,  rgba(240,183,86,1) 0%,rgba(214,160,68,1) 100%);
    filter: progid:DXImageTransform.Microsoft.gradient( startColorstr='#f0b756', endColorstr='#d6a044',GradientType=0 );
}


The credit goes to Fublo Blog for designing such great Tag designs , I have made them usable for Blogger Users

There are more Label designs that I will be sharing in the coming days , so stay tuned

Til next time,
Prayag Verma at 07:54
